KTM MACINA SPORT SX 20 US flaming black (grey+orange)
KTM MACINA electric bikes with the new compact Bosch SX motors (2 kg) set a new standard in electric bike quality - light, powerful and with outstanding performance - whether you're travelling, adventuring or training hard. The KTM MACINA starts from 15 kg!
2 549,25 €
3 399,00 €
Product is available
Only %1 left
SKU
024353516-1
EAN
9008594488328
Product | KTM MACINA SPORT SX 20 US flaming black (grey+orange) |
---|---|
SKU | 024353516-1 |
Brand | KTM |
Frame material | Aluminium |
Engine | Bosch |
Rāmis/Frame | Macina Trekking Offroad Alloy 6061 CPT400Wh Bosch BDU31 / T-4110 |
---|---|
Dakša/Fork | Suntour NCX32-D Air LO 63mm |
Amortizators/Shock | - |
Transmisija/Transmission | 1x9 Shimano CUES |
E-sistēma/E-System | BOSCH CPT-SX4P2 |
Dzinējs/Motor | Bosch PERFORMANCE SX SMART SYSTEM - 25km/h / 55Nm |
Displejs/Display | Bosch PURION 200 Display & Remote SMART SYSTEM |
Akumulators/Battery | Bosch PowerTUBE 400Wh SMART SYSTEM compact |
Lādētājs/Charger | Bosch Compact Charger 2A SMART SYSTEM |
A pārslēdzējs/R deraill | Shimano CUES U4000-9 shadow |
Pārslēdz svira/Shiflev | Shimano CUES U4000-9 display |
Klaņi/Cranckset | KTM E-TEAM2 ISIS 170mm Q8 |
P zobrats/Chainring | KTM aluminium 42T Direct Mount |
Kasete/Sprocket | Shimano LG400-9 / 11-46T |
Ķēde/Chain | KMC e500 LG e-bike |
Bremzes/Brake | Shimano MT201 / MT200 2-Piston |
B Rotors/B Rotor | Shimano RT30 CL 180 / 160 |
P rats/F wheel | KTM Line - Shimano Deore M6000 CL 32H 100-5QR Black Jack Ready25 32H 622x25TC DT Champion 2.0 black |
A rats/R wheel | KTM Line - Shimano CUES TC500 CL 32H 142-12TA Black Jack Ready25 32H 622x25TC DT Alpine II 2.34 black |
Riepas/Tires | Schwalbe G-One Overland SuperGround TLE 45-622 |
Stūre/Bar | KTM Comp II low rizer 640mm |
Stute/Stem | KTM +20° ICR |
Sēdeklis/Saddle | Selle Royal Explora Gel |
Svars kg/Weight kg | 20.9 |
Max kopējais svars kg/System weight kg | 132 |
- Kompakts jaunākās paaudzes Bosch SX dzinējs ar svaru tikai 2 kg
- 400 Wh akumulators ar kapicitātes palielināšanas iespējām līdz 650 Wh
- Atsaucīgi sensori un dzinējs nodrošina momnetāno efektīvo jaudu līdz pat 600 W amortizatoru
KTM has been making bycicles since 1964 and this year marks the 60th anniversary of the company, which is also being celebrated with a special series of bikes marked "1964". With KTM REVELATOR road bikes UCI ProSeries team B&B Hotels-KTM has successfully competed in the Tour de France, the world's most important race, and Paris-Roubaix, the toughest one-day race. The Singer Racing team on a KTM SCARP PRIME bike has won a round of the UCI MTB World Cup.
Manufacturer's size indications
S
145 cm
165 cm
M
165 cm
177 cm
L
172 cm
187 cm
XL
182 cm
196 cm
Thank you for choosing our online shop. We will do our best to get your purchase to you as quickly and safely as possible! Delivery times depend on the stock location and the delivery method and location you choose. If delivery times are particularly important to you, please contact us before you buy to clarify delivery times.
Indicative delivery times from different warehouses:
- AstraVelo store in Riga: 2-7 days
- AstraVelo warehouse in Riga: 2-7 days Manufacturer's warehouse in EU: 7-30 days
- Pre-order: 30-90 days
Delivery costs in Latvia, Lithuania and Estonia:
- by courier 10€
- delivery by parcel 5€
- Bicycles, large items and items weighing over 20 kg are delivered by courier only
Preparation and dispatch of the bike:
- Usually the bike is delivered in the manufacturer's packaging and is almost (90%) ready to use. The buyer will need a few simple tools to prepare it for use. Although it is not very difficult to assemble and prepare the bike for use, we recommend using a professional bike mechanic.
- If you want us to prepare the bike for use and send it to you in special packaging, please choose the additional service "Assembling, inspecting and packing the bike" when you make your purchase. Delivery may take 1-2 days more.
- Buyer assumes responsibility for assembling and preparing the bicycle for use if an appropriate service is not selected
Availability of goods:
- The online shop indicates the real-time availability of the goods, however, it may change rapidly
- If for any reason the goods are not available, AstraVelo will inform the Customer within 3 (three) working days via e-mail or telephone using the contact details provided in the contact information about the unavailability of the goods and offer another delivery date, replacement with an equivalent product
- If the Customer does not accept the offered delivery date or the offered product, the Customer has the right to withdraw from the contract and request a refund of the funds. AstraVelo will provide a refund to the Buyer within a maximum of 5 (five) working days from the date of cancellation
- In some cases, the description, photograph and packaging of the goods in the online shop may differ from the actual appearance or description of the goods. The description of the product shall prevail
Return of goods and other terms:
- AstraVelo ensures delivery of goods by courier to the specified/selected address or parcel station
- Delivery of goods is provided by Omniva, Venipak, DPD or other equivalent postal/courier company
- Within 30 days, the buyer may withdraw from the purchase of the goods by delivering the goods to the AstraVelo shop in Riga, Gunāra Astras iela 5.
- The returned goods must be free of defects, unused and in the original packaging.
- For other terms and conditions, see AstraVelo Online Shop Terms and Conditions
Contacts:
- Consultations and information about the products Latvian, English, Russian: [email protected], +371 20305544
- Information about the status of the online shop order Latvian, English, Russian: [email protected] +371 29502006
